Specification Table Hardware Display External Communication Digital Pulse Axis Communication x 32 + Pulse x 2 Built-in IO(Max.) No CIO (Max.) 22 input / 21 output x 8 COM1 RS232 COM2 RS232 / RS422 / RS485 COM3 No Web Interface 1 USB 1 Storage 1GB CF Card Front Button No MPG 1 Voltage 2 Fast I 2 OP No KB Operation 1 Trigger Signal No Software Path 2 Macro Axis Control Yes Macro Yes PLC Axis Control Finding origin,jog,positioning,follow,limit,MPG,speed mode,coordinate offset,PLC compensation PLC Yes Communication API (Library) Yes High Precision/Speed Yes Built-in Communication Yes Open HMI Yes File and Program Management Yes 2D File Import Yes
Specification Table Hardware Display External Communication Pulse Pulse Axis Pulse x 6 + Step x 2* Built-in IO(Max.) 40 in／32 out CIO (Max.) 22 input / 21 output x 8 COM1 RS232 COM2 RS232 / RS422 / RS485 COM3 RS422 / RS485 Web Interface 1 USB 1 Storage 1GB CF Card Front Button No MPG 1 Voltage 2 Fast I 2 OP No KB Operation 1 Trigger Signal 2 Software Path 2 Macro Axis Control Yes Macro Yes PLC Axis Control Finding origin,jog,positioning,follow,limit,MPG,speed mode,coordinate offset,PLC compensation PLC Yes Communication API (Library) Yes High Precision/Speed Yes Built-in Communication Yes Open HMI Yes File and Program Management Yes 2D File Import Yes
